Double-Sided Beveled Edge Floor Standing LED Outdoor Digital Signage

Double-Sided Beveled Edge Floor Standing LED Outdoor Digital Signage
Double-Sided Beveled Edge Floor Standing LED Outdoor Digital Signage
Double-Sided Beveled Edge Floor Standing LED Outdoor Digital Signage
Double-Sided Beveled Edge Floor Standing LED Outdoor Digital Signage
Double-Sided Beveled Edge Floor Standing LED Outdoor Digital Signage
Double-Sided Beveled Edge Floor Standing LED Outdoor Digital Signage

Double-Sided Beveled Edge Floor Standing LED Outdoor Digital Signage

Double-sided outdoor waterproof LED billboard with all-aluminum structure, applied to plaza, community entrance, highway side, etc.

  • Item No :

    LED-CT250-AB
  • Size :

    1480*2590*250
  • Brightness :

    2500
  • resolution ratio :

    1920*1080
  • Material :

    Aluminum Structure
  • Color :

    Black / Silver / Grey / Custom
  • Waterproof grade :

    IP65
  • Weight :

    200kg



Outdoor double-sided bevel LED digital signage



Double-sided vertical outdoor advertising machine, all-aluminum structure,waterproof



vertical digital signage



All aluminum construction



Advertising machine shell all made of aluminum alloy, anticorrosion and anti-rust



vertical signage design





Heat dissipation structure



CNLC outdoor film LCD monitor with internal fan cooling.aluminum structure, toensurethat the heat inside the box willnot accumulate for a long time



vertical digital signage display





Suitable for various harsh environments



IP65 waterproof and dustproof, outdoor resistance tohigh and low temperatures -30°+60



digital signage vertical display





Automatic brightness adjustment



Automatic screen brightness adjustment according to the surrounding brightness



led signage displays





Environmental Monitoring System



Real-time remote viewing of digital signage usage



led signage manufacturers



Application Scenarios







Specification







 Display





Panel Size P4:320*160
Resolution 1920x1080/4K
LCD Manufacturer BOE/LG/AUO( Industrial grade panel, 105°C TN heat resistant panel, wide workingtemperature-30~+110°C)
Viewing angle 89/89/89/89(L/R/U/D)
Contrast ratio 1200:1
Brightness 700nits as standard (1500nits/2500nits can be customized)
Aspect Ratio 16:9
Active Area 940x1580mm
Operational Life Cycle-MTBF(hours) 50K hours
Grey to Grey ResponseTime (ms) 6Ms


 Power


Input Voltage AC110- 240±10%, 50/ 60 HZ
 Leakage Protection 30mA/0.1S
 Built-in Power Socket 1 pCs (EU/US/UK/AU/Swiss Standard optional, more sockets are optional)
 Timer Switch 1 pes
 Max Power Consumption(W) TBD

Endosure Material
Enclosure Material Fully Aluminum Housing ( Anti-corrosion &. rust-proof with 15 years lifetime)
Glass Type 6mmm tempered glass as standard
6mm Tempered glass as standard with Double side AR surface treatment with hightransparency, reducing reflection/ UV/IR (optional)
6mmn ternpered glass with AG coating, anti-glare surface treatrent reduce reflection(optional)
Double Laminated AR Glass 3mm+3mr is optional (optional)
Glass Characteristics Transmmissivity > 93%, Reflectivity < 2%
Optical Bonding (Optional) Tempered Glass & LCD Display&Touch optical bonding technology is optional
protection Grade Not waterproof
Thickness 185mm


Emironrment

Operating Environment
Fully Outdoor for All Weathers
Operating Temp.
-30℃~+1110°C
Operating Humidity
5%~98%
Operating Altitude (m)
≦2000
Built-in HDMIinput MonitorVideo Board
HDMI input
1 pcs, Support 1920*1080, 4K resolution is optional
Signal Output
VoyOne or LVDS




 Free Remote ContentManage ent Software (ForAndroid only)




 Editing Playlist, timing, playback
 Edit Multi Zones play different contents
 One Video/image splicing to ultiple screens by software, no need for extra controller/matrix/HDMl splitter
 Support live stream, URL, Youtube Video, PDF. WORD, TXT. etc
 Remote Management by mobile, pC thru wif/lan network
 Support 4K high-resolution video, Max uploading video 2GB, Max uploading image 20MB
 Support Simple UsB sticker plug-play looping images/videos
 Cloud base software is supported
 Free of charge




PCAP TouchScree(Optional)



 Touch Type  PCAP Touch
Touch Max Resolution
4980*4980
Transparency
> 90%, up to 100%
Scanning Speed
> 50s scans/s
Responsive Time
<12ms
Touch Precision
0.625mm
Minimnum Touch
5mm
Cormmunication
USB port



Media & Connectivity&Other




Optional functions


Heater
Camera/webcam
Customized external Sensor
AC air conditioner
Microphone
Emergency button
